/procedural-clouds-threejs

name: procedural-clouds
description: >
  Generate beautiful procedural clouds in Three.js using WebGPU raymarching with WebGL2
  billboard/mesh fallbacks. Covers all 10 major cloud genera (cumulus, stratus, cirrus,
  cumulonimbus, stratocumulus, altocumulus, altostratus, nimbostratus, cirrostratus,
  cirrocumulus) with physically-inspired lighting including silver linings, god rays,
  sunset coloring, and Mie/Rayleigh scattering approximation. Provides volumetric
  raymarching, billboard impostor, and mesh-cluster rendering paths with animated drift,
  morphing, and dynamic formation/dissipation. Use when building skies, cloudscapes,
  weather systems, flight scenes, atmospheric backgrounds, or any scene requiring
  clouds. Triggers: "procedural clouds", "cloud rendering", "volumetric clouds",
  "skybox clouds", "cloudscape", "cumulus", "cirrus", "storm clouds", "cloud shader",
  "cloud billboard", "raymarched clouds", "cloud lighting", "god rays", "sky rendering".

Procedural Clouds

Generate visually stunning procedural clouds in Three.js with artistic emphasis — volumetric raymarching on WebGPU, billboard/mesh fallbacks on WebGL2.

Architecture Overview

┌──────────────────────────────────────────────────────┐
│                  Cloud Pipeline                       │
│                                                      │
│  Rendering Paths (select by capability + budget):    │
│                                                      │
│  ┌─ VOLUMETRIC (WebGPU) ─────────────────────────┐   │
│  │  Fullscreen quad → raymarching fragment shader │   │
│  │  Noise: 3D worley/perlin compute textures     │   │
│  │  Best quality, most expensive                  │   │
│  └───────────────────────────────────────────────┘   │
│                                                      │
│  ┌─ MESH CLUSTER (WebGL2/WebGPU) ────────────────┐   │
│  │  Instanced soft-particle spheres              │   │
│  │  Per-instance density, color, fade            │   │
│  │  Good quality, moderate cost                   │   │
│  └───────────────────────────────────────────────┘   │
│                                                      │
│  ┌─ BILLBOARD (WebGL2, mobile) ──────────────────┐   │
│  │  Camera-facing quads with noise texture       │   │
│  │  Cheapest, suitable for backgrounds           │   │
│  └───────────────────────────────────────────────┘   │
│                                                      │
│  Shared Systems:                                     │
│  Lighting ─ Drift ─ Time-of-Day ─ Formation         │
└──────────────────────────────────────────────────────┘

Cloud Classification Quick Reference

| Genus | Altitude | Shape | Key Visual | |-------|----------|-------|------------| | Cumulus | Low (2km) | Puffy mounds | Flat base, cauliflower tops | | Stratus | Low (2km) | Flat sheet | Uniform grey blanket | | Stratocumulus | Low (2km) | Lumpy rolls | Patchy blanket with gaps | | Cumulonimbus | Low→High | Towering anvil | Massive vertical, dark base | | Altocumulus | Mid (2-6km) | Rippled patches | "Mackerel sky" pattern | | Altostratus | Mid (2-6km) | Thin veil | Sun visible as bright spot | | Nimbostratus | Mid (2-6km) | Thick dark sheet | Continuous rain cloud | | Cirrus | High (6-12km) | Wispy streaks | Ice crystal hooks and mares' tails | | Cirrostratus | High (6-12km) | Thin milky haze | Halo around sun | | Cirrocumulus | High (6-12km) | Tiny ripples | Delicate fish-scale pattern |

Full profiles with shader parameters in `references/cloud-types.md`.

Renderer Setup

import * as THREE from 'three';

async function createRenderer(canvas) {
  let renderer, gpuAvailable = false;
  try {
    const WebGPU = (await import('three/addons/capabilities/WebGPU.js')).default;
    if (WebGPU.isAvailable()) {
      const { default: WebGPURenderer } = await import(
        'three/addons/renderers/webgpu/WebGPURenderer.js'
      );
      renderer = new WebGPURenderer({ canvas, antialias: true });
      await renderer.init();
      gpuAvailable = true;
    }
  } catch (e) { /* fallback */ }
  if (!renderer) {
    renderer = new THREE.WebGLRenderer({ canvas, antialias: true });
    renderer.toneMapping = THREE.ACESFilmicToneMapping;
    renderer.toneMappingExposure = 1.2;
  }
  renderer.setSize(innerWidth, innerHeight);
  renderer.setPixelRatio(Math.min(devicePixelRatio, 2));
  return { renderer, gpuAvailable };
}

3D Noise Foundation

All cloud rendering depends on layered 3D noise. These functions are shared across all three rendering paths.

// GPU-friendly 3D hash (no lookup tables)
// Used in shaders — JavaScript equivalent for CPU cloud mesh placement
function hash3(x, y, z) {
  let h = x * 127.1 + y * 311.7 + z * 74.7;
  return (Math.sin(h) * 43758.5453) % 1;
}

// 3D value noise
function noise3D(x, y, z) {
  const ix = Math.floor(x), iy = Math.floor(y), iz = Math.floor(z);
  const fx = x - ix, fy = y - iy, fz = z - iz;
  const ux = fx * fx * (3 - 2 * fx);
  const uy = fy * fy * (3 - 2 * fy);
  const uz = fz * fz * (3 - 2 * fz);

  const h = (a, b, c) => hash3(ix + a, iy + b, iz + c);
  return lerp(uz,
    lerp(uy, lerp(ux, h(0,0,0), h(1,0,0)), lerp(ux, h(0,1,0), h(1,1,0))),
    lerp(uy, lerp(ux, h(0,0,1), h(1,0,1)), lerp(ux, h(0,1,1), h(1,1,1)))
  );
}
function lerp(t, a, b) { return a + t * (b - a); }

// FBM for cloud density
function cloudFBM(x, y, z, octaves = 5, lac = 2.0, gain = 0.5) {
  let sum = 0, amp = 1, freq = 1, max = 0;
  for (let i = 0; i < octaves; i++) {
    sum += noise3D(x * freq, y * freq, z * freq) * amp;
    max += amp; amp *= gain; freq *= lac;
  }
  return sum / max;
}

Path 1: Volumetric Raymarching (WebGPU)

The highest-quality path renders clouds by marching rays through a density field defined by 3D noise. Implemented as a fullscreen post-process pass.

Cloud Density Field

The density function defines cloud shape, coverage, and type:

// GLSL-style pseudocode for the density functi
