x-dev-pipeline

x-dev-pipeline

中文说明

Current release: v1.0.0

An auditable development workflow for AI coding agents: requirement contracts, implementation evidence, deterministic checks, and risk-matched review.

x-dev-pipeline lets a spec own requirement scenarios, a dev-checklist own execution state, and a dev-report own verification conclusions. Every delivery can be traced, reconciled, and returned to the exact step that broke.

Two working paths

Large work follows the four-step main line; small tasks close in a single document:

Full flow:  x-spec → x-req → x-dev → x-verify (Gate ①) → x-qa-gate (Gate ②) → delivered
              write       split      line-by-line     delivery            quality
              requirements tasks      TDD              reconciliation      review

Small task: x-qdev (one task doc: requirements → tests → implementation → verification)

Main line: spec → req → dev → verify

1. x-spec · Write requirements

Turn an agreed conversation into a purely functional spec: docs/spec/<spec-name>/spec.md.

• Fixed structure: title + overview + a featNN list, where each feat is a feature the user can name.
• Every feat carries Given/When/Then scenarios covering normal, boundary, and error cases; THEN describes only what the user can observe.
• No technical vocabulary anywhere (no "database", "API", "cache") — the user can read every line.
• Defaults chosen where the request was silent go into a closing "to confirm" list for one-shot review.

## feat02: Search books by title

Users can quickly find books by searching for a title.

Scenario 1: Match found
- GIVEN the home page lists "Three-Body" and "Three-Body II"
- WHEN the user types "Three-Body" into the search box
- THEN both books are shown

Scenario 2: No match
- GIVEN no book on the home page contains "novel" in its title
- WHEN the user searches for "novel"
- THEN a "no matching books" message is shown

2. x-req · Split into tasks

Group feats into tasks, one development checklist per task: docs/spec/<spec-name>/tasks/<task-name>/dev-checklist.md.

• Task rows only reference scenarios as featNN scenarioM and never copy the GIVEN/WHEN/THEN — the spec stays the single source of truth.
• Row order is implementation order; no dependency graph. Merged together, all task rows cover every feat and every scenario in the spec.
• Risk column: rows touching auth, persistence, concurrency, or irreversible operations are marked 高: (high) and demand real-chain verification.
• Below the table sits an affected-files tree (U add / M modify / D delete) that matches the "files involved" column one to one.

| # | Task | Scenario refs | Files | Risk | Status |
|---|------|---------------|-------|------|--------|
| T1 | Group data structure and creation | feat01 sc.1-3 | src/groups.py | None | [ ] ⏳ |
| T2 | Join group via invite code | feat02 sc.1-5 | src/groups.py, src/join.py | None | [ ] ⏳ |

## Affected files

```text
reading-club/
├── src/groups.py        M  # group data structure, creation checks, invite codes
└── src/join.py          U  # add: join via invite code, nickname checks, limits
```

3. x-dev · Line-by-line TDD

x-dev executes a single task: from T1 downward, tests first, implementation second — never the reverse.

• Mark the current row [ ] ▶️, write a test for each scenario it references (the scenario's THEN is the assertion), watch it fail, implement until green, then mark [x] 🟢.
• Changes stay inside the affected-files tree — no drive-by edits. Rows marked 高: require smoke-or-above real-chain verification.
• After every row is 🟢, run the task's full test suite plus one regression pass over existing tests.
• dev-report.md records conclusions only — all green or N 🔴, regression result, high-risk row coverage — never pasted test output.

4. x-verify · Gate ① delivery reconciliation

x-verify audits the delivery evidence chain. It does not re-run tests and does not judge implementation quality: with spec scenarios as the source of truth, it reconciles the checklist against the dev-report —

1. Valid refs: every featNN scenarioM exists in the spec;
2. Tree consistency: no off-tree files, no missing files;
3. Closed row state: every task row is [x] 🟢 with no ⏳ / ▶️ / 🔴 leftovers;
4. High-risk rows: the dev-report declares real-chain verification;
5. Consistent conclusions: the dev-report matches the checklist state.

A full pass prints only a receipt. Problems are returned by origin — spec structure to x-spec, refs/tree to x-req, report contradictions to x-dev, known failures to x-fix.

🛡️ Gate① verify ✅ · task-group-management · rows 3/3 🟢 · refs 8/8 valid · tree consistent · high-risk 1 (declared) · conclusions consistent

Check flow: two gates

Gate ① (x-verify above) guards the consistency of the document evidence chain; Gate ② (x-qa-gate) guards the quality of the implementation itself. After verify passes, routing follows the task's risk:

Risk	Typical scope	Gate ② route
Q0/Q1	Single-file tweak / local feature or fix	Deliver directly, no reviewers
Q2	New feature, multiple files, contract or state change	One lean tri-lens reviewer
Q3	Security, irreversible writes, public API/schema, concurrency or state-machine change	One full tri-lens reviewer

Gate ② x-qa-gate: tri-lens review

A reviewer exhaustively checks three independent lenses in a single round; no lens can substitute for another:

• q1-intent: does the implementation align with user intent, acceptance scenarios, existing public contracts, and the declared scope;
• q2-correctness: illegal input, boundaries, failure paths, state transitions, concurrency, idempotency, resource cleanup;
• q3-evidence: do tests and verify evidence truly reach the changed paths, and could the assertions kill a broken implementation.

Reviewers are read-only and return problem candidates only (lens + task + severity P0/P1/P2 + loc + msg), never edits. The main agent double-checks each candidate, then registers them one by one through xdev.py flag into an issue ledger with issue-<n> IDs, downgrading checklist rows as it goes: P0/P1 become [!] 🔴; P2 is logged without blocking.

Rework loop: flag → x-fix → incremental review

Gate ①/② findings
   ├─ document inconsistency → returned to x-spec / x-req / x-dev by origin
   └─ P0/P1 → flag registers issues → x-fix batch-fixes them all at once
                → focused counterexample + one full verify re-run → incremental review
                → at most 3 rounds (fix-counter); on pass the checklist rises to [x] ✅

• x-fix processes the complete issue list in one batch — no drip-feeding; every P0 solidifies one re-runnable counterexample.
• The main agent closes issues with regression evidence and never sends fixes back to the original reviewer.
• When a fix expands into new files or public API signatures, a trimmed reviewer checks only the new boundary.
• Gate ① and Gate ② share the three-round fix counter; it resets to zero after a final quality-review pass.

x-qdev: single-doc loop for small tasks

Concrete, well-scoped single changes — "add a search box", "fix the export bug" — skip the four-step main line. x-qdev first searches docs/spec/*/spec.md for an owning spec: if found, the task doc lives at docs/spec/<spec-name>/tasks/task-<task-name>.md and references its feat; if the user confirms no spec is needed, it creates a standalone doc at docs/task/task-<task-name>.md.

It then completes four sections in one task document — the document is the deliverable:

1. ① Requirements — functional language: direction, boundaries (do / don't), invariants that must not break;
2. ② Test cases — written first and failing at this point: unit + smoke, e2e as needed, boundaries mandatory;
3. ③ Implementation — steps and files involved, turning ② green;
4. ④ Verification results — real pasted output plus invariant regression results; the four conclusion checkboxes must match the actual content.

Before delivery it runs a five-item self-check gate on the document itself: structure, valid refs, closed coverage, consistent conclusions, boundary audit — no other skill required. Out-of-scope tasks (multi-module, requirements still open, high risk) are redirected to the full x-spec + x-req flow.

✅ x-qdev done · task-todo-search · tests 5/5 passed · invariant regression passed · files changed 1

Optional: adversarial spec risk review

A spec package can pass an independent risk gate before task decomposition (x-spec → x-adversarial-risk → x-req):

x-spec records 1–5 complexity and importance scores; x-bug2rag/scripts/home_corpus.py initializes ~/.x-dev-pipeline/rag/ and copies the plugin seed corpus to risk-catalog.md as a separate operation. Risk review and bug ingestion share that user-global corpus across projects, and an explicit caller path can override it. x-adversarial-risk performs one Top5 vector lookup per budget, using retrieved experience to build minimal counterexamples that distinguish a correct implementation from a common wrong one, and adds scenarios with adversarial-review provenance to the spec. x-req blocks decomposition while the versioned spec's review status is still pending.

Commands

Command	Purpose
/x-spec	Write requirements as a purely functional spec (feats + GWT scenarios)
/x-req	Split feats into tasks and generate scenario-ref dev-checklists
/x-dev	Execute one task line by line with TDD and write a conclusions-only dev-report
/x-verify	Gate ①: reconcile the delivery evidence chain and triage by origin
/x-qa-gate	Gate ②: tri-lens quality review and flag issue ledgers
/x-qdev	Single-doc loop for small tasks: requirements → tests → implementation → verification
/x-fix	Batch-fix the issue list found by verify, gates, or CR
/x-cr	Investigate a reported correctness issue, module, diff, or PR
/x-adversarial-risk	Challenge a spec's risk assumptions and add traceable counterexample scenarios
/x-multi-llm-align	Align a protocol, data structure, or process across agents
/x-audit-perf	Run an independent performance audit
/x-audit-style	Run an independent style audit
/x-audit-arch	Run an independent architecture audit

Deterministic engine

skills/x-dev/scripts/xdev.py is the thin unified CLI for mechanical rules outside skill prose. Its engines live with their owning skills: package validation in skills/x-spec/scripts/validator.py, task planning in skills/x-req/scripts/req.py, verification in skills/x-verify/scripts/verify.py, and QA issue transactions in skills/x-qa-gate/scripts/flag.py:

validate [pkg...]                 validate specs, changes, and task contracts
status <task-dir> [--json]        parse checklist progress
graph <task-dir> [--json]         calculate ready work and parallel batches
instructions <artifact> --task    return task artifact instructions
scaffold <task-dir>               create only missing task artifacts
verify <task-dir> [--json]        execute evidence and reconcile Scenarios
flag <task-dir> --task T2,T3 --severity P0 --loc src/a.py:10 --msg "..." [--new-round] [--json]

Task commands only accept docs/spec/<spec-name>/tasks/<task-name>/. Historical dev-pipeline/tasks/ directories remain readable artifacts and have no runtime validation or orchestration support.
